Electronic braking performance monitoring system (EBPMS)
In stock now
Ensure your fleet of trailers meets the latest DVSA guidance with our easy-to-install electronic braking performance monitoring system, keeping your fleet safe, compliant and on the road.
See our Packages
Compliance with Regulatory Standards
Compliance with Regulatory Standards
Lower Maintenance Costs & Off-Road Time
Fantastic Price Point & Quick Installs
What is EBPMS?
An Electronic Braking Performance Monitoring System (EBPMS) is designed to continuously monitor and record the braking performance of trailer brakes. By using data from the trailer’s electronic braking system (EBS) and other onboard sensors, it delivers valuable insights to fleet managers. These insights help ensure safer operations, support regulatory compliance, and enable more efficient maintenance planning.
The system works by autonomously collecting data during every braking event, capturing parameters such as speed changes and demand pressure from the EBS. It then analyses this information to calculate a braking performance value. Real-time monitoring allows the system to flag any underperformance, alerting fleet managers to take corrective action before issues escalate, ensuring consistent brake effectiveness across the fleet.
EBPMS also supports DVSA regulatory compliance by providing verifiable data that can be used as part of a preventative maintenance program, potentially reducing reliance on traditional roller brake tests. With early detection of brake issues and data-driven maintenance scheduling, fleet operators can benefit from improved trailer uptime, enhanced safety, and significant cost savings.
The EBPMS must meet specific technical requirements, including:
-
Providing braking performance values with a 95% confidence interval and less than 3% margin of error
-
Using data that minimizes invalid influences such as ABS cycling or improper speeds
-
Using data that minimizes invalid influences such as ABS cycling or improper speeds
-
Excluding data where braking demand pressure cannot be met by the towing vehicle
How has the DVSA’s Guidance changed?
Vehicle operators and drivers are legally required to keep their vehicles roadworthy when operating on public roads. The DVSA’s Guide to maintaining roadworthiness recommends best practices for commercial vehicle maintenance, including a preventative inspection regime for brakes on vehicles and trailers. It strongly advises using a calibrated roller brake tester during safety inspections and recommends brake testing with the vehicle or trailer laden.
To address the impact of this new brake testing guidance, the DVSA have defined the performance requirements for an electronic brake performance monitoring system (EBPMS), giving real-time insights and reporting that reduces the need for regular roller brake testing.
Save over £1000 per year, per trailer with the Fonix EBPMS Solution.
Benefits of an EBPMS on Trailer Fleets
Lower Maintenance Costs
- Identifies brake issues early, reducing the need for emergency repairs.
- Improves component lifespan through condition-based maintenance.
- Minimises downtime by streamlining diagnostics and repair planning.
The Fonix EBPMS integrates with all major Electronic Braking Systems
Fonix EBMPS Packages
Trailer EBPMS
The Trailer EBPMS package provides you with 2 x trailer compliance reports. One individual trailer and a collective fleet report with a simple traffic light system to display the trailer performance results.
Trailer Detailed Report
Trailer Summary Report
EBPMS Alerting
Trailer EBPMS Plus
The Trailer EBPMS Plus package provides you with 2 x trailer compliance reports and a telematics solution. The individual trailer and summary report as well as a suite of tools to monitor and optimise the operation of your trailer.
Trailer Detailed Report
Trailer Summary Report
EBPMS Alerting
Trailer Tracking
Load Monitoring
Geofencing
Unauthorised usage
Utilisation Alerting
Why buy the Fonix EBPMS
Autonomous Compliance
Once installed, the Fonix EBPMS Unit will send information to our servers, where it will autonomously produce test results and alert you to any required actions.
Versatility
Our EBPMS device can be installed on any trailer to allow one provider for multiple trailer fleets.
Functionality
Built-in 4G Technology is used to future-proof the solution for years to come. This guarantees exceptional performance in any environment.
Quick Installation
Installation time is normally 1 hour per device, which allows units to be installed when vehicles go in for their regular service.
Price point
Our devices are at a fantastic price point. This, coupled with low installation time, allows us to offer a very cost-effective solution.
Design and Functionality
Our units are designed to withstand the harshest of environments. The hard-wearing waterproof casing protects the intelligent boards that extract the vital information from the EBS.
EBPMS FAQs
What is an Electronic Braking Performance Monitoring System (EBPMS)?
An EBPMS is a system that continuously monitors the braking performance of commercial vehicles using real-world driving data. It helps identify brake issues early, reduces the risk of breakdowns, improves safety, and supports compliance with DVSA regulations.
How does the system work?
The system gathers and analyses data from the vehicle’s braking system such as air pressure and braking force during normal driving. It calculates braking efficiency, detects imbalances, and identifies gradual performance loss without requiring scheduled brake tests.
How will this reduce costs for my fleet?
Lower repair costs by catching brake issues before they escalate. Reduce downtime, helping to avoid MOT failures, roadside prohibitions, and unscheduled workshop visits. Avoid fines and penalties by staying compliant with DVSA braking standards. Extend the life of components, such as brake pads and tyres, by preventing uneven wear. Minimise risk of incidents, leading to fewer insurance claims and operational disruptions.
Is the system compliant with UK regulations?
Yes. The system aligns with DVSA guidance in the Guide to Maintaining Roadworthiness and can provide continuous braking performance evidence. This helps operators maintain compliance, improve their OCRS score, and demonstrate effective brake monitoring in inspections or audits.
What types of vehicles is it suitable for?
It works with most HGVs, trailers, and PSVs fitted with air braking systems. We support a wide range of vehicle makes and models used in UK logistics, construction, and passenger transport.
What Brands of EBS are compatible?
Our system is compatible with all leading brands including: Knorr-Bremse, Haldex and Wabco.
What kind of reports and alerts will I receive?
• Real-time alerts for underperforming brakes. • Bi Weekly or monthly performance summaries. • DVSA-ready reports showing brake test results. • Maintenance insights to help with service planning and defect rectification.
How can I access the data?
Everything you need for your compliance will be emailed directly to you. However, you can access performance data and reports via our secure online portal should you want to.
Is installation complicated?
Not at all. We offer a nationwide installation service through our own network of experienced technicians, ensuring minimal disruption to your operations. If you prefer to install it in-house, self-installation is also available — please get in touch for technical guidance and support.
What is the return on investment (ROI)?
Fleets typically see a strong ROI through: • Fewer unscheduled repairs • Improved vehicle uptime • Extended component life • Reduced risk of fines and incidents It’s a cost-effective way to stay compliant while improving safety and operational efficiency.
Can we set up scheduled braking performance reports?
Yes. You can schedule automated braking performance reports to be delivered straight to your inbox on a 30-day or bi-weekly basis. These reports help you stay informed about your fleet’s braking health and identify any emerging issues promptly.
What are the EBPMS Contract Lengths?
We are very flexible in terms of our EBPMS contract length. We understand that operators do not want to be tied into long contracts . Our EBPMS packages can have short term contracts depending on your custom requirement.
